Classic FM sounds, effortlessly merged with FM FUSION.
Using the 4-track sequencer and presets, you can construct an entire song.
Three Fusion FM Engines X-LAB Engine
Merge two FM sounds with a single knob to create a completely new sound.
XFORM Engine
Transform one FM sound into another over a specific period of time.
X-LFO Engine
Continuously transform between two FM sounds using an LFO.
Over 300 Inspiring Preset Sounds
Ready-to-use presets including, leads, keyboards, strings, winds, basses, pads, chords, drums, and sound effects.
Two approaches to FM sound design
Intuitive and Quick
Merge and sculpt FM sounds with a single, intuitive, knob turn.
The X-Lab engine merges two FM sounds by smoothly blending their envelopes, modulation routing, and feedback. The X-Lab algorithm can merge sounds with radically different FM structures and overtones, all without losing the fundamental tuning of the sound. Pitch locking can also be turned off to create brilliant atonal transitions between FM sounds.
Merged sound can then be saved, recalled, and merged with additional FM sounds. This is called merging process FUSION FM.
Logical and Deep
For those who want to dive into the FM Engine, the EDIT mode and included overlay provide full access to the innovative 4-OP XFM engine.
15 knobs and 30 buttons provide quick and intuitive access to all FM parameters.
Explore FM synthesis without the conventional menu diving and head scratching.
4-Track Step Sequencer
Perfect for song production and live performance
Manage lead, bass, rhythm, and more, each on separate tracks.
Sequence up to 64 steps per pattern.
Save up to 128 patterns.
The parameter locking function allows you to record knob changes into your patterns. This automation function can be recorded live, or programmed in step by step.
Sub-divide the tempo down to 32nd notes for higher resolution sequencing.
Sequence longer notes across several steps, AKA Tied Notes.
Specifications:
Size
297mm (W) x 176mm (D) x 48mm (H)
11.7 in (W) x 6.92 in (D) x 1.89 in (H)
Weight:
790g / 1.74lb.
Keyboard:
27 keys (with a hold function)
Knob:
15 physical control knobs
Optional LATCH function prevents jumps in value when knob position and parameter values do not match. LCD dot indicates when a parameter value matches the saved value, or when the value has been changed.
One physical encoder
Audio output:
Stereo line out (stereo 3.5mm mini jack)
Headphone out (stereo 3.5mm mini jack)
Compatible with Teenage Engineering Pocket Operator2 Series SYNC OUT
Speaker
Audio in:
LINE IN (stereo 3.5mm mini-jack)
Compatible with Teenage Engineering Pocket Operator 2 Series SYNC IN
Interfaces:
MIDI IN connector (5-Pin DIN type)
MIDI OUT connector (5-Pin DIN type)
SYNC IN jack (monaural 3.5mm mini jack)
SYNC OUT jack (monaural 3.5mm mini jack)
Power supply:
9V DC output AC adapter
Current: 1A or greater
Plug Type: EIAJ3 Standard
Inner Diameter: 1.7mm
Outer Diameter: 4.75mm,
Polarity: Center +
Compatible with power supplies designed for the Korg Volca 1 .
6 AA batteries
Synth Engine:
Four FM synth engines, X-LAB, XFORM, X-LFO, and LIBRARY
Voice mode:
6-note polyphonic mode
Mono mode
Legato mode with adjustable glide time
Arpeggiator modes (Up, Down, UpDown, DownUp, Up&Down, Down&Up, Up+1, Up+2, Down-1, Down-
2, Random, Play Order)
Sweep:
Sweep with adjustable speed, range, and curve
Filter
Low Pass
High Pass
Band Pass
Each track has its own filter envelope.
Effects:
Chorus
Flanger
Send Delay
Insert Delay
Bit Crusher
Reverb
Distortion
Low Pass
High Pass
Isolator
LFO:
Each track has one LFO which can affect both pitch and filter cutoff.
Adjustable LFO Shapes.
Adjustable start time delay for each LFO.
Sound memory:
512 FM sound memory slots (16 x 32 banks)
Sequencer:
4 tracks
Up to 64 steps per pattern
128 patterns
Step length can be set from 1 / 1 to 1 / 32
Enter longer notes (Tie)
Track level and pan can be set independently
FX send amount can be set independently for each track
Pattern BPM / Global BPM can be set
Step copy and paste function
Track copy and paste function
Transpose function
Real-time recording
Directly enter notes for each step when sequencer is on or off
Parameter lock function
Random playback function (Playback step size can be set)
Stutter function
Note Trigger probability can be set between 25% and 100%
Pattern chain function
Metronome and pre-count function
Swing function
MIDI:
Notes, control changes, clock input / output
IMPORT / EXPORT of user data
Firmware update via Sysex
Accessories:
FM sound editing overlay
Warranty
The AC adapter is not included.
Please use 9V DC output AC adapter (1A or higher, EIAJ3 standard inner diameter 1.7mm outer diameter 4.75mm, center +).
Compatible with power supplies designed for the Korg Volca 1.
